ASCENT-18 ROCK CRAWLER

The classically styled Ascent-18 is available in three body color options (Blue, Red orGraphite)

FRONT TILT BODY MOUNTING SYSTEM

Body is hinged at the front for a clean look as well as quick access toelectronics

PORTAL AXLES

BEARING SUPPORTED METAL AXLE GEARS

SMALL PACKAGE BIG PERFORMANCE

Built for fun – Built to perform – Built tolast

REDCAT CLASSIC WHEELS

Classically styled off road wheels wrapped with aggressive 60mm open lug soft compound rubbertires

PERFORMANCE TUNED SHOCKS

Aluminum capped oil filled coilovershocks

4-LINK SUSPENSION & METAL CHASSIS FRAME

REDCAT MULTI-CHANNEL RADIO & RECEIVER

Ascent-18 comes with 750mAh LiPo battery, USB charger, multi-channel radio with 2-in-1receiver

Vehicle Scale :

1/18

Engine / Motor

RC180 Brushed Motor

Transmission

Forward & Reverse

Drive System

4 Wheel Drive

Length

218mm

Width

130mm

Height

114mm

Servo Type

4kg Metal Gear Waterproof Servo

Wheelbase

155mm

Ground Clearance

42mm

Chassis Type

2mm Flat Rail Aluminum

Wheel Width

15mm

Wheel Diameter

25.5mm

Suspension

Aluminum Capped Oil Filled Shocks

Speed Control Type

2in1 ESC/Receiver Brushed

Radio System

2.4GHz Radio System

Battery

7.4v 750mAh LiPo with USB Charger Included

Needed to Run

4 AA Batteries for Radio
